Abbreviated as PCB, the printed circuit board is a thin plate which holds electronic components. PCBs can be found in most, if not all, electronic devices. It is a key component of electronics.
Through the years, developments in both the materials and production methods used have contributed to the advancement of the design of printed circuit boards. This article will discuss how PCBs are made.
Printed circuit boards are composed of layers of different materials fused and laminated together using adhesives and heat. The substrate part of the PCB gives the board its thickness and rigidity. This layer is usually made of fiberglass, but other materials like epoxy can be used as well. The copper foil gives the board conductive surfaces and is where components are soldered or stamped. Depending on the design and purpose of the board, the copper can be on one side, both sides, or in multiple layers of the board. The copper areas are laminated with a thin layer of lead to prevent oxidation.
Making the substrate
The roll of woven fiber glass is unwound and then fed to the process station where it is coated with epoxy resin, either by spraying or dipping. The coated fiberglass is then passed through rollers until the desired thickness is achieved. This process also removes the excess resin.
The substrate is then semicured by passing it through an oven. The substrate is cut into panels after the curing.
The large panels are then stacked in layers, with the copper foil in between and then pressed together while being subjected to high temperature. This process fuses the copper foil to the substrate’s surface and also cures the resin fully.
Plating and drilling the holes
A few panels of the substrate are stacked, one on top of the other, and are held together to keep them from moving. Holes are then drilled according to the design or pattern desired. The holes are cleaned to remove extra material clinging from the edges.
The inner surfaces of the holes that are meant to conduct are coated with copper. The other holes are plugged to prevent them from being coated.
Etching the circuit pattern on the board
The printed patterns on printed circuit boards are created using either an additive or a subtractive process. Copper is added or plated onto the substrate’s surface according to the predetermined pattern. If using the additive process, the rest of the surface is left unplated. When using the subtractive process, the whole surface of the substrate is plated with the copper foil then the areas that are not part of the desired pattern are removed through etching. Tin-lead is added to the surface of the copper foil to protect it from oxidation.
Adding the contact fingers
Contact fingers are added to the substrate’s edge so that they connect with the circuit print. The area is masked and then plated. The plating materials applied (in order) are tin-lead, nickel, and gold.
Sealing and cutting the panels
The panels are sealed with epoxy which protects the circuit patterns from getting damaged while the electronic components are being attached. This is also the part where instructions, symbols, and other marking are added through silkscreen stencil.
When the stenciling process is finished, individual printed circuit boards are then cut from the panels. The edges of the boards are then smoothed.
If the PCBs will not be used immediately in production, they are packaged individually into protective plastic wraps (often the antistatic kind) and then stored or shipped.
Those are the basic steps in the manufacture of printed circuit boards.
Printed circuit boards with Pcbnet are composed of layers of different materials fused and laminated together using adhesives and heat.
